Nano-1 Laser Model

The Nano-1 Laser Model is the model belonged to Nanolaser family of Q-switched, DPSS lasers. These are high-peak-power, rugged, turnkey, nanosecond units with output at any or all of the wavelengths: 1064 nm, 532 nm and 266 nm. The relatively short pulse length and high peak power make the Nano-1 Laser Model particularly suitable for use in LIDAR, km-scale laser ranging (at 1064 nm), micromachining, mass spectrometry and other applications.

Features

• Compact, self-contained laser
• 1 ns and shorter output pulse width
• Near TEM 00 beam quality
• Repetition rate up to 400 Hz
• External computer control of repetition rate and output energy via the built-in RS232 port

Applications

• LIDAR and Laser ranging
• Laser Induced Fluorescence (LIF)
• MALDI Mass Spectrometry
• Micromachining, marking, engraving
• Laser ablation, fragmentation
• Photoionization, LIBS
• Medicine

Content and Delivery

The delivered laser consists of the following
• Integrated Laser Head/Power Unit
• Power Cable
• Test Record.
• CD with Control Application (upon request)

Warranty

1 year for all parts and labor excluding the laser pump diode. The pump diode is warranted for the lesser of 1 year or 10 nano pulses.
